Bias Tees BT523628
2022-05-09 11:23:07 点击：
❶Features:*10 MHz to 6 GHz
*500 mA & 50 VDC
*VSWR＜1.5
*Insertion Loss＜1.0 dB max.
*Isolation: 30 dB typ.
❷Application:
*Amplifier Biasing
*Coax
*DC Return/ Block
*Test & Measurement
*Wireless Systems
*Transmitting Power With a single
*Communication Systems
❸Description:
10 MHz to 6 GHz SMA Bias Tees, 500 mA & 50 VDC BT523628 bias tees (also called bias T) has a SMA connector RF port that is female gender. This Yach female SMA bias tee design is rated for a minimum frequency of 10 MHz and a maximum frequency of 6 GHz. This SMA bias tee / T is rated for a max. DC voltage of 50 Volts and a max. current of 500 mA. The BT523628 bias T with SMA connector series for RF port is designed with a maximum VSWR of 1.5:1 and a RF to bias isolation typical of 30 dB. Yach's RF bias tee accept customization. Common modeles are in stock, the fastest delivery on the same day. Welcome to your inquires!
文件下载：BT523628.pdf (点击右键可另存)
