RF Rotary Joints RJ518236
2022-08-12 18:35:07 点击：
❶Features:*Dual Channels Rotary Joints
*Impendance: 50 Ohm
*CH1: 19.4 to 21.2 GHz
*CH2: 29.1 to 31 GHz
*Peak Power: 1000 Watts max
*Average Power: 10 Watts max
*VSWR: 1.5
*Insertion Loss: 0.8 dB
*CH1: 2.92 Female
*CH2: 2.92 Female
*Lifetime: 10 Million Revolutions min
❷Application:
*Laboratory Applications
*R&D Labs
*Radar Systems
*Microwave Radio Systems
*Test Instrumentation
*Military & Space
*Communication Systems
*Satellite Communications
*Wireless Communications
❸Description:
*RJ518236 is a dual Channels Rotary Joints, operating frequency CH1: 19.4 to 21.2 GHz, CH2: 29.1 to 31 GHz. The rotary joints have 10 Watts max of average power, rf rotary joints has a VSWR of 1.5 and an insertion loss of 0.8 dB. Yach.com's rotary joints have 2.92 Female connectors for CH1 and CH2. Yach.com's RF rotary joints accept customization. Common modeles are in stock, the fastest delivery on the same day. Welcome to your inquires!
文件下载：RJ518236.pdf (点击右键可另存)
