RF DC Blocks DB200160
2022-05-06 18:11:25 点击：
❶Features: *50 KHz to 40 GHz *VSWR＜2.0 *Insertion Loss＜2.0 dB max. *Handling Power 2 Watts ❷Application: *Test & Measurement *Signalto Noise Ratio (SNR) *Ground Loop Elimilation *Improvement
❸Description: DB200160 is a coaxial RF DC block is from Yach.com and has an 50 Ohm impedance. Our 50 Ohm DC block is manufactured with a SMA input and SMA output.
Yach.com SMA DC block is rated for a minimum frequency of 50 KHz and a maximum frequency of 40 GHz. DB200160 SMA DC block has a maximum insertion loss of 2.0 dB and a maximum VSWR of 2.0:1.
Yach.com's RF dc blocks accept customization. Common modeles are in stock,the fastest delivery on the same day. Welcome to your inquires!
文件下载：DB200160.pdf (点击右键可另存)
