RF DC Blocks DB200157
2022-05-06 18:05:33 点击：
❶Features: *10 MHz to 26.5 GHz *VSWR＜1.6 *Insertion Loss＜1.5 dB max. *Handling Power 2 Watts ❷Application: *Test & Measurement *Signalto Noise Ratio (SNR) *Ground Loop Elimilation *Improvement
❸Description: DB200157 is a coaxial RF DC block is from Yach.com and has an 50 Ohm impedance. Our 50 Ohm DC block is manufactured with a SMA input and SMA output.
Yach.com SMA DC block is rated for a minimum frequency of 10 MHz and a maximum frequency of 26.5 GHz. DB200157 SMA DC block has a maximum insertion loss of 1.5 dB and a maximum VSWR of 1.6:1.
Yach.com's RF dc blocks accept customization. Common modeles are in stock,the fastest delivery on the same day. Welcome to your inquires!
文件下载：DB200157.pdf (点击右键可另存)
