Cable Assemblies TC522127
2022-08-11 17:05:57 点击：
❶Features:*Economy Interconnection Cable
*Frequency: DC to 26.5 GHz
*Cutoff Frequency: 61 GHz
*Impedance: 50 Ω
*Velocity of Propagation: 80 %
*Shielding Effectiveness: 90 dB Min
*Voltage Power: 500 VDC
*Static Bend Radius: 13 mm
*Dynamic Bend Radius: 26 mm
*Weight: 0.02 Kg/m
*Installation&Operating Temperature: -55°C~+165°C
❷Application:
*Laboratory Applications
*R&D Labs
*Radar Systems
*Telecom Infrastructure
*Microwave Radio Systems
*Test Instrumentation
*Military & Space
*Communication Systems
*Satellite Communications
*Wireless Communications
❸Description:
*TC522127 is an economy interconnection cable, impedance 50 Ω, operating frequency in the DC to 26.5 GHz. The cutoff frequency is 61 GHz, the velocity of propagation is 82%. Yach.com's coax cable TC522127 is 90 dB min of shielding effectiveness, 500 VDC of voltage power, 13 mm of static bend radius. 26 mm of dynamic bend radius. Yach.com's RF coax testing cable accept customization. Common modeles are in stock, the fastest delivery on the same day. Welcome to your inquires!
文件下载：TC522127.pdf (点击右键可另存)
