Cable Assemblies TC522126
2022-08-11 16:59:46 点击:
❶Features:
*High Precision Test Cable
*Frequency: DC to 26.5 GHz
*Cutoff Frequency: 29 GHz
*Impedance: 50 Ω
*Velocity of Propagation: 82 %
*Shielding Effectiveness: 90 dB Min
*Voltage Power: 2000 VDC
*Static Bend Radius: 25 mm
*Dynamic Bend Radius: 50 mm
*Weight: 0.055 Kg/m
*Installation&Operating Temperature: -55°C~+165°C
❷Application:
*Laboratory Applications
*R&D Labs
*Radar Systems
*Telecom Infrastructure
*Microwave Radio Systems
*Test Instrumentation
*Military & Space
*Communication Systems
*Satellite Communications
*Wireless Communications
❸Description:
*TC522126 is a high precision test cable, impedance 50 Ω, operating frequency in the DC to 26.5 GHz. The cutoff frequency is 29 GHz, the velocity of propagation is 82%. Yach.com's coax cable TC522126 is 90 dB min of shielding effectiveness, 2000 VDC of voltage power, 25 mm of static bend radius. 50 mm of dynamic bend radius. Yach.com's RF coax testing cable accept customization. Common modeles are in stock, the fastest delivery on the same day. Welcome to your inquires!
*High Precision Test Cable
*Frequency: DC to 26.5 GHz
*Cutoff Frequency: 29 GHz
*Impedance: 50 Ω
*Velocity of Propagation: 82 %
*Shielding Effectiveness: 90 dB Min
*Voltage Power: 2000 VDC
*Static Bend Radius: 25 mm
*Dynamic Bend Radius: 50 mm
*Weight: 0.055 Kg/m
*Installation&Operating Temperature: -55°C~+165°C
❷Application:
*Laboratory Applications
*R&D Labs
*Radar Systems
*Telecom Infrastructure
*Microwave Radio Systems
*Test Instrumentation
*Military & Space
*Communication Systems
*Satellite Communications
*Wireless Communications
❸Description:
*TC522126 is a high precision test cable, impedance 50 Ω, operating frequency in the DC to 26.5 GHz. The cutoff frequency is 29 GHz, the velocity of propagation is 82%. Yach.com's coax cable TC522126 is 90 dB min of shielding effectiveness, 2000 VDC of voltage power, 25 mm of static bend radius. 50 mm of dynamic bend radius. Yach.com's RF coax testing cable accept customization. Common modeles are in stock, the fastest delivery on the same day. Welcome to your inquires!
文件下载:TC522126.pdf (点击右键可另存)
