Power Amplifiers PA8375239
2022-05-24 18:40:48 点击：
❶Features:*Frequency: 2 GHz to 18 GHz
*Gain: 45 dB typ
*VSWR: 2.0 max
*Psat: 42 dBm typ
*Supply: AC 220V/ 50Hz
*Input/Output Connector: SMA Female
❷Application:
*Laboratory Applications
*R&D Labs
*Radar Systems
*Electronic Warfare
*Wireless Systems
*Test Instrumentation
*Communication Systems
*Power Amplifier
*RF Front Ends
*Low Noise Amplifiers
*Microwave Radio Systems
❸Description:
*PA8375239 is a broadband rf power amplifier, operating frequency in the 2 to 18 GHz. The amplifiers offer 43 dB min signal gain, with the gain flatness of ±5 dB typ, the power amplifier has a VSWR of 2.0 max. Yach.com's broadband power amplifier PA8375239 is rated Psat 42 dBm typ output power, this amplifier needs a single positive AC supply 220 Volts/ 50Hz, the amplifier has SMA female connectors for input/output ports. Yach.com's RF power amplifiers accept customization. Common modeles are in stock, the fastest delivery on the same day. Welcome to your inquires!
文件下载：PA8375239.pdf (点击右键可另存)
