RF DC Blocks DB200155
2022-05-06 17:37:26 点击：
❶Features: *10 MHz to 18 GHz *VSWR＜1.8 *Insertion Loss＜1.2 dB max. *Handling Power 2 Watts ❷Application: *Test & Measurement *Signalto Noise Ratio (SNR) *Ground Loop Elimilation *Improvement
❸Description: DB200155 is a coaxial RF DC block is from Yach.com and has an 50 Ohm impedance. Our 50 Ohm DC block is manufactured with a SMA input and SMA output.
Yach.com SMA DC block is rated for a minimum frequency of 10 MHz and a maximum frequency of 18 GHz. DB200155 SMA DC block has a maximum insertion loss of 1.2 dB and a maximum VSWR of 1.8:1.
Yach.com's RF dc blocks accept customization. Common modeles are in stock,the fastest delivery on the same day. Welcome to your inquires!
文件下载：DB200155.pdf (点击右键可另存)
