Cable Assemblies TC522130
2022-08-11 16:51:36 点击:
❶Features:
*Phase & Amplitude Stable Cable
*Frequency: DC to 18 GHz
*Cutoff Frequency: 20 GHz
*Impedance: 50 Ω
*Velocity of Propagation: 83 %
*Shielding Effectiveness: 90 dB Min
*Voltage Power: 2500 VDC
*Static Bend Radius: 37 mm
*Dynamic Bend Radius: 74 mm
*Weight: 0.116 Kg/m
*Installation&Operating Temperature: -55°C~+165°C
❷Application:
*Laboratory Applications
*R&D Labs
*Radar Systems
*Telecom Infrastructure
*Microwave Radio Systems
*Test Instrumentation
*Military & Space
*Communication Systems
*Satellite Communications
*Wireless Communications
❸Description:
*TC522130 is a phase & amplitude stable cable, impedance 50 Ω, operating frequency in the DC to 18 GHz. The cutoff frequency is 20 GHz, the velocity of propagation is 83%. Yach.com's coax cable TC522130 is 90 dB min of shielding effectiveness, 2500 VDC of voltage power, 37 mm of static bend radius. 74 mm of dynamic bend radius. Yach.com's RF coax testing cable accept customization. Common modeles are in stock, the fastest delivery on the same day. Welcome to your inquires!
*Phase & Amplitude Stable Cable
*Frequency: DC to 18 GHz
*Cutoff Frequency: 20 GHz
*Impedance: 50 Ω
*Velocity of Propagation: 83 %
*Shielding Effectiveness: 90 dB Min
*Voltage Power: 2500 VDC
*Static Bend Radius: 37 mm
*Dynamic Bend Radius: 74 mm
*Weight: 0.116 Kg/m
*Installation&Operating Temperature: -55°C~+165°C
❷Application:
*Laboratory Applications
*R&D Labs
*Radar Systems
*Telecom Infrastructure
*Microwave Radio Systems
*Test Instrumentation
*Military & Space
*Communication Systems
*Satellite Communications
*Wireless Communications
❸Description:
*TC522130 is a phase & amplitude stable cable, impedance 50 Ω, operating frequency in the DC to 18 GHz. The cutoff frequency is 20 GHz, the velocity of propagation is 83%. Yach.com's coax cable TC522130 is 90 dB min of shielding effectiveness, 2500 VDC of voltage power, 37 mm of static bend radius. 74 mm of dynamic bend radius. Yach.com's RF coax testing cable accept customization. Common modeles are in stock, the fastest delivery on the same day. Welcome to your inquires!
文件下载:TC522130.pdf (点击右键可另存)
