6 GHz to 12 GHz Low Noise Amplifier, NF 2.5 dB, Psat 26 dBm, Gain 42 dB, SMA Female, PN: LNA824479, $1999
更新：2022-06-02 18:28:51 点击：
❶Features:
*X Band Coaxial Low Noise Amplifier
*Frequency: 6 GHz to 12 GHz
*Noise Figure: 2.5 dB max
*VSWR: 1.5 typ
*Output Power (P1dB): 25 dBm min
*Supply: +12~+15 VDC, 300 mA typ
*Input/Output Connector: SMA Female
❷Application:
*Laboratory Applications
*R&D Labs
*Radar Systems
*Telecom Infrastructure
*Microwave Radio Systems
*Low Noise Amplifier
*General Purpose Amplification
*Gain Block
*Test Instrumentation
*Military & Space
*Communication Systems
*Satellite Communications
*Wireless Communications
❸Description:
*LNA824479 is a X band coaxial low noise amplifier (LNA), operating frequency in the 6 to 12 GHz. The low noise amplifier offers 2.5 dB max noise figure, the low noise amplifier has a VSWR of 1.5 typ. Yach.com's low noise amplifier LNA824479 is rated 25 dBm min output power (P1dB), this low noise amplifier needs a single positive DC supply +12~15 Volts 300 mA typ, the low noise amplifier has SMA female connectors for input/output ports. Yach.com's RF low noise amplifiers (LNA) accept customization. Common modeles are in stock, the fastest delivery on the same day. Welcome to your inquires!
详情
Pricing:
| Quantity (pcs) | Price ($) |
| 1-2 | 1999 |
| 3-5 | 1989 |
| 6-10 | 1979 |
| 11-19 | 1969 |
|
≥20 |
1959 |
Datasheet to download
Key Specifications：
|
Minimum Frequency |
6 GHz |
|
Maximum Frequency |
12 GHz |
|
Noise Figure |
2.5 dB max |
|
RF Input VSWR |
1.5:1 typ |
|
RF Output VSWR |
1.5:1 typ |
|
Output Power (Psat) |
25 dBm min |
|
Supply |
+12~15 VDC, 300 mA typ |
|
Input Connector |
SMA Female |
|
Output Connector |
SMA Female |
