10 MHz to 26.5 GHz RF DC Blocks 50 Ohm SMA Female Rated 25 Volts 2 Watts, PN: DB200157, $299
更新：2022-05-24 17:17:51 点击：
❶Features:
*10 MHz to 26.5 GHz *VSWR＜1.6 *Insertion Loss＜1.5 dB max. *Handling Power 2 Watts
❷Application:
*Test & Measurement *Signalto Noise Ratio (SNR) *Ground Loop Elimilation *Improvement
❸Description:
*DB200157 is a coaxial RF DC blocks (also called dc block)are from Yach.com and have an 50 Ohm impedance. Our 50 Ohm DC blocks are manufactured with a SMA input and SMA output.
Yach.com SMA DC blocks are rated for a minimum frequency of 10 MHz and a maximum frequency of 26.5 GHz. DB200157 SMA rf DC blocks have a maximum insertion loss of 1.5 dB and a maximum VSWR of 1.6:1.
Yach.com's RF dc blocks accept customization. Common modeles are in stock, the fastest delivery on the same day. Welcome to your inquires!
详情
Pricing:
| Quantity (pcs) | Price ($) |
| 1-4 | 299 |
| 5-9 | 289 |
| 10-24 | 279 |
| 25-49 | 269 |
|
≥50 |
259 |
Datasheet to download
Key Specifications：
|
Minimum Frequency |
10 MHz |
|
Maximum Frequency |
26.5 GHz |
|
Maximum VSWR |
1.6:1 |
|
Insertion Loss |
1.5 dB max. |
|
Maximum Voltage |
25 VDC |
|
Handling Power |
2 W min. |
| Impedance |
50 Ω |
| Connector | SMA Female |
